16

Pendant Transmitter

(AS-TVBPT)

Oscillation type

Selectable Frequencies

Microphone

Pre-programmed 96 switchable frequencies

Electrical Condenser

PLL Synthesized control OSC

Frequency Range

640~664 MHz

RF Power

Max. Modulation

T.H.D

Hi: below 10 dBm and Low: 4± 2 dBm

±80 kHz, with level limiting

< 1% @ f = 1 kHz, MIC IN = -30 dBv

Tone Frequency / Modulation

S/N

38 kHz / 2.5

± 0.5 kHz.

>60 dB @ with AS-TVBPR, f = 1 kHz,
MIC IN = -30 dBv

Operating Range

MIC / AUX in connector

LCD display

Dimensions

Weight

Frequency Response

Batter y

DC Current

Batter y life

Batter y full charge time

Hi: > 50 M, Low: >30 M @ with AS-TVBPR,
Open Field face to face

3.5 mm jack

Channel, Frequency, Battery.

88 x 52 x 34 mm

75 kgs

Aux 70 Hz ~ 12 kHz
Mic 100 Hz ~ 12 kHz
Mic 70 Hz ~ 12 kHz

Li-ion 3.7V 1200 mAh

Hi power: 85

± 10 mA;

Low Power: 65 ± 10 mA @ 3.7 V

Hi power up to 12 hours
Low power: up to 16 hours

3 ~ 4 hours @1200 mAh Type.

AUX Modulation level

7 ± 0.5 kHz @level=-20 dBv, f=1 kHz. MID

Operating Range
