26 www.fxpansion.com
by increasing the output level of each bandpass filter. This is useful for rim-shot
sounds, and like the harmonics control can add ‘bite’. This is followed by a simple
tone control filter. See the next two pages for more information on DrumSynth008.
PARAMETERS
1 Level Osc1 amplitude (pre hard clipping)
1 Freq Osc1 centre frequency
1 Decay Osc1 envelope decay time
2 Level Osc2 amplitude (pre hard clipping)
2 Freq Osc2 centre frequency
2 Decay Osc2 envelope decay time
1 Harmonics Osc1 waveshaping distortion (left=odd, right=even)
1 Width Osc1 bandwidth (or sweep startpoint if following parameter set)
1 Sweep Osc1 frequency sweep time
2 Shape Osc2 envelope shape from logarithmic (sharp) to linear (full)
2 Width Osc2 bandwidth
2 Attack Osc2 envelope attack time
Filter Tone control filter (left=lowpass, right=highpass)
Level Trim Output level trim (post hard clipping)
Waveform Select waveform: TR-808 cowbell/ride, TR-909 open hat/closed
hat/crash/ride
WaveTune Waveform transpose
Wave Mix Waveform mix with white noise generator
Trigger Number of triggers
Trig Delay Time between each trigger
Trig Decay Decay rate between each trigger
Key Release Release time (100% = ignore key release)
Polarity Invert Osc1 polarity - some filter settings will phase against
each other
Start Phase Starting phase for both oscillators - adds an adjustable DC click
Vel > Frq1 Velocity control of Osc1 frequency
Vel > Lev1 Velocity control of Osc1 level
Vel > Frq2 Velocity control of Osc2 frequency
Vel > Lev2 Velocity control of Osc2 level
Vel > Wave Velocity control of waveform transpose
Vel > Tone Velocity control of tone control filter
