Futaba 10CG 2.4GHz User Manual
Page 103
103
DELAY
: The Delay function provides a smooth transition between the trim positions whenever OFFSET, REVO. MIXING, or
THROTTLE HOLD
functions are turned on and off.
Adjustability:
• Separate delay times are available for aileron, elevator, rudder, throttle, and
pitch.
• With a 50% delay setting, the servo takes about a half-second to move to its
new position...quite a long time.
,QJHQHUDOGHOD\VRIDSSUR[LPDWHO\DUHVXI¿FLHQW
GOAL of EXAMPLE:
STEPS:
INPUTS:
Set up a delay on all channels to ease
WKH WUDQVLWLRQ IURP RQH ÀLJKW FRQGLWLRQ
to another so there are no "hard jumps."
Open the DELAY function.
for 1 second.
(If BASIC,
again.)
C
to DELAY.
Adjust AILE response as needed. (Ex:
aileron to +8%.)
to +8%.
Repeat for other channels.
C
to ELEV. Repeat step above.
C l o s e m e n u s a n d c o n f i r m s l o w e d
transitions.
E (T10CHG) or G (T10CAG)
from NORMAL to IDL2. Check that servos
move gradually to new positions.
Where next?
THR-HOLD
: see p. 99.
Setting up the Idle-Ups: Throttle and Collective pitch Curves and Revo. Mixing
(THR-CURVE, PIT-CURVE, REVO. MIX) for idle-ups: see p. 101.
