DAD 141.1 Technical Manual Modbus Communication, Rev. 2.3 - Juni 2014 Page 7
2102 Int32 2 RW Analog High This Index defines the weight value for the high analog output.
The 32 bit integer data accessed by reading or writing 2 16-bit registers from index 2102.
see also command description:
AH Analog High
2104 Int32 2 RW Analog Low This Index defines the weight value for the low analog output.
The 32 bit integer data accessed by reading or writing 2 16-bit registers from index 2104.
see also command description:
AL Analog Low
2106 Int32 2 RW Filter Setting This Index is used to select the filter setting.
The 32 bit integer data accessed by reading or writing 2 16-bit registers from index 2106.
The values of the low pass filters are 0 to 7.
see also command description:
FL Filter Value
210A Int32 2 RW Logic Output This Index Reads/Modify the status of the physical output signals.
The 32 bit integer data accessed by reading or writing 2 16-bit registers from index 210A.
see also command description:
IO Status of the logic Output
210C Int32 2 R Logic Input This Index reads the status of the physical input signals.
The 32 bit integer data accessed by reading or writing 2 16-bit registers from index 210C.
see also command description:
IN Read status of logic Input
210E Int32 2 RW Measuring Time See index 2410
2110 Int32 2 RW Filter Mode This Index chooses the filter mode, permitted values are “0” for IIR and “1” for FIR.
The 32 bit integer data accessed by reading or writing 2 16-bit registers from index 2110.
see also command description:
FM Filter Mode
2112 Int32 2 RW No Motion
Range This Index Reads/Modify the maximum number of counts allowed as no motion.
The 32 bit integer data accessed by reading or writing 2 16-bit registers from index 2112.
see also command description:
NR No Motion Range
2114 Int32 2 RW No Motion Time This Index Reads/Modify the minimum time the weight must stay within NR to be no motion.
The 32 bit integer data accessed by reading or writing 2 16-bit registers from index 2114.
see also command description:
NT No MotionTime
2116 Int32 2 RW Logic Output
Mask This Index Reads/Modify the mask of the logic Outputs.
The 32 bit integer data accessed by reading or writing 2 16-bit registers from index 2116.
see also command description:
OM Control of logic Outputs
2118 Int32 2 R Tare Value This Index Reads the Tare value.
The 32 bit integer data accessed by reading 2 16-bit registers from index 2118.
see also command description:
GT Get tare value
211A Int32 2 RW Start Delay See index 2412
211C Int32 2 RW Trigger Edge See index 2402
211E Int32 2 RW Trigger Level See index 2400
Index (hex) Type Size Access Function Description
2120 Int32 2 RW Update Rate This Index chooses Average after the filter by 2 exp. UR samples.
The 32 bit integer data accessed by reading or writing 2 16-bit registers from index 2120.
