Flintec DAD 141.1 Modbus Communication User Manual
Page 4
DAD 141.1 Technical Manual Modbus Communication, Rev. 2.3 - Juni 2014
Page
4
Index (hex)
Type
Size Access Function
Description
202E
Int32
2
R
Firmware
Version
This Index returns the current Firmware version of a DAD141.
The 32 bit integer data is obtained by reading 2 16-bit registers from index 202E.
The the high word (202E) are 0 (zero) and the low word (202F) should be split into two bytes:
1. Byte is the minor IV, e.g. 02h (02d).
2. Byte is the major IV, e.g. 17h (23d).
see also command description:
IV Firmware Version
2030
Int32
2
R
Device Status
This Index returns the current Status for a DAD141.
The 32 bit integer data is obtained by reading 2 16-bit registers from index 2030.
see also command description:
IS Device Status
2034
Int32
2
R
Serial Number
This Index returns the serial number of the DAD141.
The 32 bit integer data is obtained by reading 2 16-bit registers from index 2034.
see also command description:
RS Read Serial Number
2060
Int16
1
R
Qualifier
This Index returns the latest Qualifier value obtained from a DAD141.
The 16 bit integer data is obtained by reading one 16-bit registers at index 2060.
The Qualifier bit values are:
0001h - Under range
0002h - Over range
0010h - No motion, still stand, steady state
0020h - Tare set
0100h - Set-point 0 (source>limit)
0200h - Set-point 1
0400h - Set-point 2
The Qualifier word are also sent when reading multiple DAD141 data at index 3300 or 3500.
2061
Int16
1
W
Bit Commands
This Index is used to set or reset Zero, Tare or Max / Valley / Peak2Peak.
The 16 bit integer data is accessed by writing one 16-bit register at index 2061.
see also command description:
01h:
RZ Reset Zero
02h:
SZ Set Zero
04h:
RT Reset Tare
08h:
ST Set Tare
10h:
RM Reset Max
20h:
TH Trigger Hold
2062
Int16
1
W
Trigger
This Index is used to trigger measurements in the DAD 141.1.
The 16 bit integer data is accessed by writing one 16-bit register at index 2062.
The value 0080h starts the triggered measurement.
see also command description:
TR Software Trigger
Index (hex)
Type
Size Access Function
Description
2066
Int16
1
W
Save in
This Index is used to Initiate writing to the DAD141 EEPROM.
