DAD 141.1 Technical Manual Modbus Communication, Rev. 2.3 - Juni 2014 Page 10
Index (hex) Type Size Access Function Description
2412 Int32 2 RW Start Delay This Index Reads/Modify the delay between falling/rising edge of the trigger pulse and start of the
measurement. The 32 bit integer data accessed by reading or writing 2 16-bit registers from index
2412.
see also command description:
SD Start Delay
3006 Int32 2 R MAC Hi This Index reads the four most significant bytes of the MAC address.
The 32 bit integer data accessed by reading 2 16-bit registers from index 3006.
3008 Int32 2 R MAC Lo This Index reads the two least significant bytes of the MAC address.
The 32 bit integer data accessed by reading 2 16-bit registers from index 3008.
300C Int32 2 RW IP Address This Index reads/Modify the IP Address. A change will take effect after reset.
The 32 bit integer data accessed by reading or writing 2 16-bit registers from index 300C.
see also command description:
NA Network Address
3300 Int32
Int32
Int16 5 R Combined
result, integer This index reads the gross weight, the net weight and the qualifier.
The 32 bit integer data accessed by reading or writing 2 16-bit registers from index 3300.
see also command description:
GW Get data string “net, gross and status“
3500 Float
Float
Int16 5 R Combined
result, floating
point This index reads the gross weight, the net weight and the qualifier.
The 32 bit integer data accessed by reading or writing 2 16-bit registers from index 3500.
see also command description:
GW Get data string “net, gross and status“
