Fawcett TM Upper - Hyd. Driven - Manual (Page 16)

G
P
M
RPM
and
TORQUE
A25 MOTOR
PSI
100 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400 1500
1
RPM
TORQUE
314
6
298
17
282
27
265
37
249
47
233
58
216
68
200
78
184
88
168
98
151
109
135
119
119
129
103
139
86
149
2
RPM
TORQUE
596
3
580
14
563
24
547
34
531
44
515
54
498
65
482
75
466
85
450
95
433
106
417
116
401
126
385
136
368
146
3
RPM
TORQUE
862
11
845
21
829
31
813
41
797
51
780
62
764
72
748
82
732
92
715
102
699
113
683
123
667
133
650
143
4
RPM
TORQUE
1144
8
1127
18
1111
28
1095
38
1079
48
1062
59
1046
69
1030
79
1014
89
997
99
981
110
965
120
948
130
932
140
5
RPM
TORQUE
1426
4
1409
15
1393
25
1377
35
1361
45
1344
56
1328
66
1312
76
1295
86
1279
96
1263
107
1247
117
1230
127
1214
137
6
RPM
TORQUE
1691
12
1675
22
1659
32
1642
42
1626
52
1610
63
1594
73
1577
83
1561
93
1545
104
1529
114
1512
124
1496
134
7
RPM
TORQUE
1973
9
1957
19
1941
29
1924
39
1908
49
1892
60
1876
70
1859
80
1843
90
1827
100
1811
111
1794
121
1778
131
8
RPM
TORQUE
2255
5
2239
16
2223
26
2206
36
2190
46
2174
57
2158
67
2141
77
2125
87
2109
97
2093
108
2076
118
2060
128
G
P
M
RPM
and
TORQUE
A37 MOTOR
PSI
100 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400 1500
1
RPM
TORQUE
210
14
201
29
192
44
183
59
173
74
164
88
155
103
146
118
136
133
127
148
118
163
109
178
100
192
90
207
81
222
2
RPM
TORQUE
410
9
401
24
392
39
383
53
373
68
364
83
355
98
346
113
337
128
327
143
318
157
309
172
300
187
290
202
281
217
3
RPM
TORQUE
610
4
601
18
592
33
583
48
573
63
564
78
555
93
546
108
537
122
527
137
518
152
509
167
500
182
490
197
481
212
4
RPM
TORQUE
801
13
792
28
783
43
773
58
764
73
755
87
746
102
737
117
727
132
718
147
709
162
700
177
690
192
681
206
5
RPM
TORQUE
992
23
983
38
974
52
964
67
955
82
946
97
937
112
927
127
918
142
909
157
900
171
891
186
881
201
6
RPM
TORQUE
1192
18
1183
32
1174
47
1164
62
1155
77
1146
92
1137
107
1127
122
1118
136
1109
151
1100
166
1091
181
1081
196
7
RPM
TORQUE
1392
12
1383
27
1374
42
1364
57
1355
72
1346
87
1337
101
1327
116
1318
131
1309
146
1300
161
1291
176
1281
191
8
RPM
TORQUE
1592
7
1583
22
1574
37
1564
52
1555
66
1546
81
1537
96
1528
111
1518
126
1509
141
1500
156
1491
170
1481
185
G
P
M
RPM
and
TORQUE
A50 MOTOR
PSI
100 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400 1500
1
RPM
TORQUE
156
18
153
37
150
56
146
75
143
94
140
113
136
132
133
151
129
170
126
189
122
208
118
227
115
246
111
265
107
284
2
RPM
TORQUE
306
15
302
34
299
52
296
71
292
90
289
109
285
128
282
147
278
166
275
185
271
205
267
224
264
243
260
262
256
281
3
RPM
TORQUE
456
10
453
29
450
48
446
67
443
86
439
105
436
124
432
143
429
162
425
181
421
200
418
220
414
239
410
258
406
277
4
RPM
TORQUE
608
5
605
24
601
43
598
62
595
81
591
100
588
119
584
138
580
157
577
177
573
196
569
215
566
234
562
253
558
272
5
RPM
TORQUE
752
19
750
38
747
57
745
76
743
95
741
114
737
133
733
152
730
171
726
190
722
209
718
228
714
247
710
267
6
RPM
TORQUE
902
12
901
31
900
50
898
69
895
88
892
107
890
127
888
146
884
165
880
184
877
203
873
222
869
242
865
261
7
RPM
TORQUE
1057
5
1053
24
1050
43
1048
62
1047
81
1046
100
1044
120
1042
139
1040
158
1036
177
1032
196
1028
215
1024
235
1020
254
8
RPM
TORQUE
1206
16
1205
35
1204
54
1203
74
1202
93
1200
112
1198
131
1196
150
1193
169
1189
188
1186
208
1182
227
1178
246
TORQUE
(Inch-pounds)
ORDER MOTOR BY
SIZE WITH SUFFIX:
"F" Flange Mount
Short Shaft
"FM" Pedestal Foot
Mount
"FMO" Flange Mount
Long Shaft
Hydraulic Motors
have a "letter-number-
letter" designation that
indicates the type of
motor, size of gerotor,
and mounting method
required. For example: a
motor having a 1/2 inch
gerotor and requiring
flange mounting short
shaft, would be idicated
as A50F.
Order motor with optional
features according to the
following suffixes:
"-T" Turned down flange
"-2-BOLT" Oval Flange
"-4-BOLT" Square Flange
"-A" Aluminum round flange
"-TA" Aluminum turned
down flange
"-1" One flat on shaft
"-2" Two flats on shaft
"-DT" Shaft end tapped
"-K" Longer Key
"V" with Viton seal
Refer to example on
bottom of page 2.
When selecting your
motor for a specific ap-
plication, you must re-
member that the peak
motor torque and RPM
must be sufficient to
meet the most severe
demands of the applica-
tion.
TORQUE
(Inch-pounds)
TORQUE
(Inch-pounds)
4
