FAWCETT CO.
CUSTOMER:
B/M No: 2156 D1
BY: DMM
SHEET: 1
DATE: 1/23/2003
DESCRIPTION: TRANSMIX SYSTEM COMMERCIAL PARTS
ITEM No.
No. REQ'D PART NO. NAME DESCRIPTION
201 1 BEARING ZZAPP 5205-2RS1
202
203 2 SEAL ZZACA MSE1000-250-25-01
204 2 H.D. EXT. RET. RING ZZAPP SHR-98-STPA
205 1 INT. RET. RING ZZAPP HO-218-STPAS
206 1 S.S. COMPR. SPRING ZZMCM 9435K99
207
208 1 VITON "O" - RING ZZMCM 9464234
209 1 GASKET *** SEE ITEM 109 ***
210 REF COUPLING *** SEE ITEM 107 ***
211 1 GEAR BOX ZZSUM CNFJ 4100Y 6:1
212 REF AIR MOTOR LS-130NEMA, LS-104NEMA or LS-105NEMA
212 REF HYDRAULIC MOTOR LAMINA# A25 FMO
212 REF ELECTRIC MOTOR ZZBAL VM3558 or ZZBAL VM6561
rev.#1,
