HSIM-FE6 Local Management
HSIM-FE6 User’s Guide 3-3
f
3.3 HSIM-FE6 LOCAL MANAGEMENT
For information concerning Local Management for the HSIM-FE6, refer to
the host device manual.
NOTE
A link exists if the associated port RX LED is on.
Table 3-2 10/100 LED Indications When RX LED Is On
LED Color Indication
10/100 Off FE-100TX is operating at 10 Mbps.
Green FE-100TX is operating at 100 Mbps.
NOTE
No link exists if the associated port RX LED is off.
Table 3-3 10/100 LED Indications When RX LED Is Off
LED Color Indication
10/100 Off No link or no cable attached. FE-100TX
forced to 10 Mbps operation, or is
manually set to “auto-negotiate” mode.
Green No link or no cable attached. FE-100TX is
forced to 100 Mbps operation.
