Chapter 2: Installation
2-6 HSIM-FE6 User’s Guide
5. Remove and save the two faceplate mounting screws securing the
HSIM coverplate and remove the coverplate. See
Figure 2-3 .
Figure 2-3 Removing the HSIM Coverplate
6. Refer to Figure 2-4 and place the HSIM-FE6 behind the module
faceplate.
Faceplate Mounting Screws
HSIM Coverplate
2555_03
