Equipment Instruction Manual
EDCO Models SS26-38K, SS26-31D, SS26-15E & SS36-57D
HOW TO ORDER REPAIR PARTS
To insure product safety and reliability, always use genu-
ine EDCO replacement parts when making repairs to the
equipment.
When ordering parts, please specify the MODEL and
SERIAL NUMBER of the machine as given on the NAME-
PLATE. In addition, give part number, description and
quantity as listed on the parts list.
Please note: Due to improvements and changes in the
equipment the illustrations shown may be different from
the actual machine.
Toll Free: Voice 1-800-638-3326 • Fax 1-800-447-3326
Table of Contents
Section Page Number
Safety Messages.........................................................................................................2
Specifi cations..............................................................................................................3
Safety Guidelines........................................................................................................4
Operating Instructions..............................................................................................5-9
Tracking Adjustment....................................................................................................9
Maintenance.........................................................................................................11-16
Your Notes............................................................................................................17-18
Maintenance Schedule..............................................................................................19
Limited Equipment Warranty..........................................................................back page
SS-26-38K Shown
See Chart
Below
Varies with type of bladeguard
Width
Figure 1
Length
Height
Specifi cations and dimensions are approximate
and subject to change
Model SS26-38K SS26-31D SS26-15E SS36-57D
