EcoTech Marine Rail Kit User Manual
Rail kit instructions, Rail kit parts, One short rail kit
+ONE SHORT RAIL KIT
(XR616-1)
SHORT RAIL KIT
(XR616)
+ONE LONG RAIL KIT
(XR618-1)
LONG RAIL KIT
(XR618)
RAIL KIT
INSTRUCTIONS
TM
Instructions are for the following kits:
SHORT RAIL KIT
(XR616)
LONG RAIL KIT
(XR618)
+ONE SHORT RAIL KIT
(XR616-1)
+ONE LONG RAIL KIT
(XR618-1)
(See illustration reference on inside.)
Multiple Kit Examples
®
SHORT RAIL KIT
AND
+ONE SHORT RAIL KIT
Approx. 19.5 in (49.53 cm) (2 Radions end to end)
LONG RAIL KIT
AND
+ONE LONG RAIL K
IT
1349 Lynn A
ve., Bethlehem, PA 18015
610 954 8480 800 785 0338 (toll free) 888 500 2907 (fax)
Review the parts included in the kit that you purchased.
If something is missing, contact EcoTech Marine service at
800 785 0338
(Ext. 2) or email us at [email protected].
Additional Rail Kit information available at
www.ecotechmarine.com.
If you are using a Rail Kit in conjunction with the
PREMIUM HANGING KIT
, familiarize yourself with the
hanging kit instructions before beginning. A minimum
of ONE hanging kit per TWO Radions is recommended.
Additionally, make sure that the hanging kit anchors are
capable of supporting multiple Radion fixtures.
SIDE-BY-SIDE RADION HANGING GUIDE
Number of
Radions
Hanging
Kit
Rail
Kit
+One
Kit
1
1
0
0
2
1
1
0
3
2
1
1
4
3
1
2
5
4
1
3
6
5
1
4
Rails Hangers Radions
RAIL KIT PARTS
(All kits include hex nuts for connecting multiple kits.)
Rails Radions
16 in (40.64 cm)
16 in (40.64 cm)
18 in (45.72 cm)
18 in (45.72 cm)
Approx. 17.5 in (44.45 cm) (2 Radions end to end)
Approx. 27.875 in (70.8 cm) (3 Radions end to end)
Approx. 31.875 in (80.96 cm) (3 Radions end to end)
