EcoTech Marine RMS Tank Mount User Manual
Tank mount system rms
Tank Mount System
RMS
Mounting Instructions for Radion XR30 and XR15 LED Models
6.
Spacer (optional)
5.
Clamp Chop
4.
Adjustment Screw
3.
Formed Arm
2.
X-Bracket
1.
Sliding Rail
7.
Edge Clamp
Make sure that all you have all components included in this kit before
beginning. If something is missing contact EcoTech Marine service at
1-800-785-0338 ext.2 with any questions, requests or comments.
Cable Routing
(
XR15 only
)
