Clarion VS735 User Manual
Page 27
VS735
27
VS735 in Dolby Pro Logic 5.1 System
Black - Ground
Video output -
to monitor
VS 735
IR input
Red +12V Accessory
Power Harness
Clarion
VMA 7191
monitor
Optical
digital
cable
DCA 008 or DCA 005
A/V Auxiliary inputs
A/V Output
DVH 920 CeNET
5.1 Channel
Processor
Optical input
Analog
outputs
to
amplifiers
POWER
D S F
ADJUST
A-MODE
SOURCE
DVC 920
Control Unit
for DVH 920
Processor
Video input 2
Video input 1
Video
input 1
Black -
Ground
Red +12V
Accessory
Yellow +12V Constant Power
