VS735
The VS735 installed with another head unit
VS735 in place
of factory pocket, below
radio
Factory
trim
bezel
Factory
Radio
Mounting
Bracket
Dashboard
Factory Radio
Mounting Bracket
Clarion Supplied
Screws into VS735
Clarion Supplied
Screws into VS735
Factory Trim Screws
Factory
Trim
Screws
If a hook on the installation bracket inter-
feres with the unit, bend and flatten it with
a nipper or similar tool.
4-Hexagonal screw
∗
(M5
×
8)
VS735
Factory Radio
Mounting Bracket
(1 pair for the left and right sides)
∗
:
★
:
Factory
Trim
Bezel
The screws with this mark are
enclosed with the VS 735
The parts and screws with this mark
were used to install the factory radio and/or pocket
The VS735 Installed with a factory pocket
