TECHNICAL SPECIFICATIONS

PATIENT ANALYSIS
Automatically evaluates patient impedance for proper
pad contact. Monitors signal quality and analyzes
patent ECG for shockable/non-shockable rhythms.

SENSITIVITY/SPECIFICITY
Meets AAMI-DF-80 specifications and AHA
recommendations.

PATIENT ANALYSIS SYSTEM

MODEL
Adult – DDP-2001
Child/Infant –
DDP-2002 and DDP-2003

SURFACE AREA
Adult – 77cm

2

(nominal, each pad)

Child/Infant –
50cm

2

(nominal, each pad)

TYPE
Pre-connected, single-use,
non-polarized, disposable,
self-adhesive electrodes
with cable and connector

DEFIBRILLATION / MONITORING PADS

INTERNAL EVENT RECORD
Critical ECG segments and rescue
event parameters are recorded
(greater than 60 minutes) and can
be downloaded to a removable
data card.

PC-BASED EVENT REVIEW
ECG with event tag display, and
audio playback when available.

REMOVABLE STORAGE
(optional) Up to 30 hours of
ECG and event data storage
(no audio option) or up to
3 hours of audio (audio option).

ECG and event storage on a
removable data card. Actual length
of storage is dependent on card
capacity.

USB PORT
Event download and maintenance
operations.

EVENT DOCUMENTATION

TEMPERATURE
Operating: 0 to 50°C
(32 to 122°F)
Standby: 0 to 50°C (32 to 122°F)

RELATIVE HUMIDITY
Operating/Standby: 5%-95%
(non-condensing)

ALTITUDE
-500 to 15,000ft (-150 to 4500m)
per MIL-STD-810F 500.4
Procedure ll

VIBRATION
Ground (MIL-STD-810F 514.5
Category 20)

Helicopter (RTCA/DO-160D,
Section 8.8.2, Cat R. Zone 2,
Curve G)

Jet Aircraft (RTCA/DO-160D
Section 8. Cat H, Zone 2,
Curves B & R)

SHOCK/DROP ABUSE
TOLERANCE
MIL-STD-810F 516.5 Procedure IV
48 inches (1.2 meters), any edge,
corner, or surface, in standby
mode

CRUSH TEST
1,000 pounds (450kg)

SEALING/WATER
RESISTANCE
IEC 60529 class IP55;
Dust protected, Protected against
water jets (battery pack installed)

ESD
IEC 61000-4-2: (Open air up to
15kV or direct contact up to 8kV)

EMC (Emission)
CISPR 11 Group 1 Level B and
FCC Part 15

EMC (Immunity)
IEC 61000-4-3 and
IEC 61000-4-8

AIRCRAFT
Meets RTCA/DO-160G,
Section 21, RF Radiated
Emissions, Category M

ENVIRONMENTAL

SIZE
7.3 x 9.5 x 2.3 inches (18.5 x 24 x 5.8 cm)

WEIGHT
Less than 3 lbs (1.4kg) (with battery)

PHYSICAL

Specifications subject to change without notice

TYPE
Semi-Automatic external
defibrillator

MODEL
DDU-2000 Series

WAVEFORM
Impedance Compensated
Biphasic Truncated
Exponential

RESCUE PROTOCOL
AHA/ERC 2010
Supports protocol
updates by the user
(password protected)

ENERGY*
AED Mode:

Adult: 150 Joules
Child/Infant: 50 Joules

Manual Mode:

Adult: User selectable
from 25-200 Joules
Child/Infant: User
selectable from
25-100 Joules
(50 Joules only when
using DDP-2002
attenuating pediatric
defibrillation pads)

CHARGE TIME
AED Mode:

4 seconds or less
(from shock advised)**

Manual Mode:

9 seconds or less
(150 Joules)***
12 seconds or less
(200 Joules)***

CONTROLS
Lighted ON/OFF button
Lighted Shock button

DISPLAY
High-resolution
color LCD

VIDEO PROMPTS
Full motion video
On-screen text prompts

CPR COACHING
Video and voice coaching
On-demand video help

VOICE PROMPTS
Extensive voice prompts
guide user through
operation of the unit.

DEFIBRILLATOR

*Nominal into 50 ohm load
**Typical, new battery, at 25°C
***Typical, new battery depleted
by 6 shocks, at 25°C

0 1 9 7

MODEL
DBP-2003 (standard),
DBP-2013
(aviation; TSO C-142a)

POWER
12VDC, 2800 mAh

TYPE
Lithium/Manganese
Dioxide Disposable,
recyclable, non-
rechargeable

CAPACITY*
125 shocks or 8 hours
continuous operation

STANDBY LIFE*
4 years

LOW BATTERY
INDICATIONS
Visible
Audible

BATTERY PACKS

*Typical, new battery, at 25°C

AED MODE (ALL MODELS)
High resolution video display
(animated instructions and CPR
coaching)

ECG MONITOR MODE
(DDU-2400 & 2450 ONLY)
Displays ECG data and event
information (with 3-lead
electrodes)

MANUAL MODE
(DDU-2400 ONLY)
Displays ECG data and event infor-
mation and defibrillation energy
selection from 25-200 Joules with
charge, shock and disarm control

OPERATING MODES

AUTOMATIC
Automatic daily, weekly, monthly
and quarterly circuitry tests

BATTERY INSERTION
System integrity test on battery
insertion

PAD PRESENCE
Pads preconnected tested daily

USER-INITIATED
Unit and battery pack system test
initiated by the user

STATUS INDICATION
Visual and audible indication
of unit status

STATUS SCREEN
Unit self-tests results
Pads and battery information
(status and expiration)

SELF-TESTS
