Crosman APGRM311F User Manual

Owner’s manual

GFM311 6mm Airsoft Pistol

Model # APGFM311/APGFM311S

OWNER’S MANUAL

READ ALL INSTRUCTIONS AND WARNINGS IN THIS MANUAL BEFORE USING

THIS AIRSOFT PISTOL

Crosman Corporation

7629 Routes 5 & 20

Bloomfield, NY 14469

United States of America

www.crosman.com

1-800-7AIRGUN (724-7486)

Manual Part number APGFM311-515

READ AND UNDERSTAND THIS ENTIRE MANUAL BEFORE USING THIS AIRSOFT GUN.

REMEMBER, THIS AIRSOFT GUN IS NOT A TOY. TREAT IT WITH THE SAME RESPECT YOU WOULD A FIREARM.

THIS IS NOT A TOY. ADULT SUPERVISION REQUIRED. MISUSE OR CARELESS USE MAY CAUSE SERIOUS INJURY, ESPECIALLY TO THE

EYE. EYE PROTECTION MUST BE USED BY THE USER AND ANY PERSON WITHIN RANGE. MAY BE DANGEROUS UP TO 100 YARDS (91.44 METERS). READ

OWNER’S MANUAL BEFORE USING.

YOU AND OTHERS WITH YOU SHOULD ALWAYS WEAR SHOOTING GLASSES TO PROTECT YOUR EYES.

READ ALL INSTRUCTIONS BEFORE USING.

BUYER AND USER HAVE THE DUTY TO OBEY ALL LAWS ABOUT THE USE AND OWNERSHIP OF THIS AIRSOFT GUN.

DO NOT BRANDISH OR DISPLAY THIS AIRSOFT GUN IN PUBLIC – IT MAY CONFUSE PEOPLE AND MAY BE A CRIME. POLICE AND

OTHERS MAY THINK IT IS A FIREARM. DO NOT CHANGE THE COLORATION AND MARKINGS TO MAKE IT LOOK MORE LIKE A FIREARM. THAT IS DANGEROUS

AND MAY BE A CRIME.

THIS PRODUCT CONTAINS ONE OR MORE CHEMICALS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER AND BIRTH

DEFECTS (OR OTHER REPRODUCTIVE HARM).

SAFETY FIRST

•ALWAYS treat the AIRSOFT GUN as though it is loaded and ready to fire

•ALWAYS treat AIRSOFT GUN with the same respect you would a firearm

•ALWAYS store the AIRSOFT GUN unloaded

•ALWAYS store the AIRSOFT GUN away from children

•ALWAYS aim in a SAFE DIRECTION

•ALWAYS keep the muzzle of the AIRSOFT GUN pointed in a SAFE DIRECTION

•ALWAYS keep your finger off the trigger and out of the trigger guard until ready to shoot

•ALWAYS keep the AIRSOFT GUN “ON SAFE” until you are ready to shoot (see Fig. 2)

•ALWAYS check to see if the AIRSOFT GUN is “ON SAFE” (see Fig. 2) and unloaded when handing it to or receiving it from another person

•ALWAYS have you and others wear shooting glasses to protect your eyes

•ALWAYS wear shooting glasses over eye glasses if your prescription or reading glasses are not safety glasses

•ALWAYS place the backstop in a location that will be safe should the backstop fail

•ALWAYS check your backstop for wear before and after each use. All backstops are subject to wear and will eventually fail. Replace your

backstop if the surface is worn or damaged, or if a ricochet occurs

•ALWAYS use the proper size BB in your AIRSOFT GUN. Check the markings on your AIRSOFT GUN to verify the BB size is 6mm

•NEVER reuse ammunition

•NEVER shoot at hard surfaces or at the surface of water. The BB may bounce off or ricochet and hit someone or something you had not

intended to hit

•NEVER attempt to disassemble or tamper with your AIRSOFT GUN. Modifying the function of your AIRSOFT GUN in any way, may be unsafe

and will void your warranty

•NEVER point the AIRSOFT GUN at any person or at anything you do not intend to shoot

LEARNING THE PARTS OF YOUR AIRSOFT GUN

Learning the names of the parts of your new airsoft gun will help you to understand your owner’s manual. Use this manual to increase your

enjoyment of this airsoft gun.

A. Muzzle

B. Front Sight

C. Slide

D. Rear Sight

E. Lever Safety (fig. 2)

F. Grip Safety (fig. 3)

G. Magazine

H. Magazine Release Button

I. Trigger

J. Trigger Guard

Operating the Safety

CAUTION: Like all mechanical devices, an airsoft gun safety can fail. Even when the safety is “ON SAFE”, you should continue to handle the

airsoft gun in a safe manner.

TO PUT THE AIRSOFT GUN “ON SAFE:”

•Locate the safety on the left side of the airsoft gun.

•Push the safety lever all the way up into the “ON SAFE” (“S”) position (Fig. 2).

The safety is not “ON SAFE” unless (1) it is pushed all the way up into the “S” position and (2) the airsoft gun’s slide (see Fig. 1) cannot move.

KEEP THE AIRSOFT PISTOL IN THE “ON SAFE” (“S”) POSITION UNTIL YOU ARE ACTUALLY READY TO SHOOT. THEN PUSH THE SAFETY

TO THE “OFF SAFE” POSITION.

TO TAKE THE AIRSOFT GUN “OFF SAFE”:

•Push the safety all the way down into the “OFF SAFE” (“F”) position (Fig. 2).

IMPORTANT: This airsoft pistol also has a grip safety which is automatically engaged

when the airsoft pistol is NOT gripped firmly (Fig. 3).

•To disengage the grip safety, it is necessary to firmly grasp the back of the grip.

•When the safety lever on the airsoft gun is all the way down in the “Off SAFE” (“F”)”

position, and the grip safety is disengaged by the shooter firmly gripping the

airsoft pistol, the airsoft pistol can be fired.

LOADING AND UNLOADING PLASTIC BBS

Note: For optimum performance use Crosman

, GameFace™, Marines Airsoft

or Duty

Calls

6mm plastic BBs only.

Loading Plastic BBs

•Make sure the airsoft gun is “ON SAFE” (See Step 3A) and pointed in a

SAFE DIRECTION.

•While supporting the bottom of the grip with your hand to catch the maga-

zine, press the magazine release button and remove the magazine from the

bottom of the grip frame (Fig. 4).

•Open the reservoir door (Fig. 5) by sliding the door down

•Fill the reservoir with up to 50 BBs and slide the door closed.

•Locate the BB guide on the front of the magazine. Pull the BB guide down and to the right until it locks into place (Fig. 6).

•Holding the magazine as shown, shake the magazine until up to 12 BBs feed into the magazine (Fig. 7).

•Release the BB guide by pushing the spring to the left and slowly releasing.

•Insert the loaded magazine back into the bottom of the grip frame until you hear a click, indicating the magazine is securely locked into

place (Fig. 8).

IMPORTANT: The magazine will not automatically fill from the reservoir. You will have to remove the clip and shake BBs from the reservoir into

the magazine after 12 shots.

Fig. 4

Reservoir

Fig. 5

Fig. 6

Fig. 7

Fig. 8

Press

UNLOADING PLASTIC BBS WITHOUT FIRING

•Put the airsoft gun “ON SAFE” (See Step 3A).

•Point the airsoft gun in a SAFE DIRECTION.

•While supporting the bottom of the grip with your hand to catch the magazine, press the magazine release button and remove the

magazine from the bottom of the grip frame.

•Locate the BB guide on the front of the magazine. Pull the BB guide down and to the right until it locks into place.

•Holding the magazine horizontally, slide open the reservoir door.

•Empty the BBs from the reservoir into your hand or a container.

•Rock the clip to release the BBs from the magazine into the reservoir.

•Repeat the steps above until all the BBs are out of the reservoir.

EVEN THOUGH YOU GO THROUGH THE UNLOADING PROCEDURE, CONTINUE TO TREAT THE AIRSOFT GUN AS THOUGH IT WERE

LOADED. DO NOT POINT AT ANYTHING YOU DO NOT INTEND TO SHOOT.

HOW TO COCK AND FIRE THE AIRSOFT GUN

Cocking the Airsoft Gun

•Point the airsoft gun in a SAFE DIRECTION.

•Take the airsoft gun “OFF SAFE”.

•Cock the airsoft pistol by firmly holding the

slide with your entire hand, pulling the slide

rearward and releasing it in a smooth motion

to cock (Fig. 9).

AIMING AND FIRING SAFELY

•Your airsoft gun is designed for target shooting and is suited for both indoor and outdoor use. Always

remember to place your target carefully. THINK about what you will hit if you miss the target.

•Your airsoft gun is correctly aimed when the front sight blade is positioned exactly in the notch of the rear sight.

•The top of the front sight blade should be even with the top of the notch in the rear sight. The bulls-eye should appear to rest on the top

of the front sight (Fig. 10).

•When you are sure of your target and backstop, and the area around the target is clear, take the airsoft gun “OFF SAFE” (section 3B), cock

the airsoft gun (section 5A), aim and pull the trigger to fire.

MAINTAINING YOUR AIRSOFT GUN

CAUTION:

•DO NOT ATTEMPT TO DISASSEMBLE YOUR AIR RIFLE.

•DO NOT MODIFY OR ALTER YOUR AIRSOFT GUN. Attempts to modify the airsoft gun in any way inconsistent with this manual may make

your airsoft gun unsafe to use, cause serious injury, especially to the eye and will void the warranty.

•If you drop your airsoft gun, visually check to see that it works properly before you use it again.

•If anything seems changed, like a shorter or weaker trigger pull, this may mean worn out or broken parts. Call Crosman customer service

for assistance before using your airsoft gun again.

HOW TO CLEAN THE MAGAZINE

•Remove magazine

•Wipe down outside of magazine with moist towel

•Replace magazine

TO CLEAN THE AIRSOFT GUN BARREL

•Spray a cleaning patch with Crosman Nitro Lubricant oil

•With the cleaning patch on rod (rod may not be included with your airsoft gun), insert it into barrel to clean

•Make sure rod retains cleaning patch or the patch could get stuck in the barrel of the gun

•Swab barrel 3-4 times

•Repeat swabbing procedure with a dry patch

•Barrel is clean when patches come out clean after dry swabbing

CLEARING A JAM

•If your airsoft gun jams, please contact Crosman’s customer service for assistance

SPECIFICATIONS

Mechanism:

Spring

Sights Front:

Fixed Blade

Sights Rear:

Fixed Notch

Caliber/Ammunition:

6 mm Plastic BB

Capacity:

Up to 12 BB

Velocity:

240 fps

Length

9 inches

Safety:

Lever and Grip

Weight:

2.0 lbs

PERFORMANCE: Many factors can affect velocity, including brand of projectile, type and weight of projectile and barrel condition. For optimum

performance use Crosman

, Gameface

, Marine Airsoft

or Duty Calls

branded ammunition only. Use of other airsoft ammunition may cause your

product to malfunction and may void your warranty.

90 DAY LIMITED WARRANTY

This product is warranted to the retail consumer for 90 days from date of retail purchase against defects in material and workmanship and is

transferable. You should retain the original sales receipt as record of date of purchase. If no receipt, the product is warranted for 90 days from

date of manufacture.

WHAT IS COVERED:

Product replacement

Transportation charges to consumer for product replacement

WHAT IS NOT COVERED:

Transportation charges to Crosman Corporation

Damages caused by abuse, modification or failure to perform normal maintenance – see Owner’s Manual

Any other expense

CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, OR INCIDENTAL EXPENSES INCLUDING DAMAGE TO PROPERTY. SOME LOCAL, STATE OR

FEDERAL LAWS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES SO THE ABOVE LIMITATION

OR EXCLUSION MAY NOT APPLY TO YOU.

IMPLIED WARRANTIES

ANY IMPLIED WARRANTIES INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED

IN DURATION TO 90 DAYS FROM DATE OF RETAIL PURCHASE. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY

LASTS SO THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.

To the extent any provision of this warranty is prohibited by federal, state or municipal law, which cannot be preempted, it shall not be

applicable. This warranty gives you specific legal rights and you may have other rights, which vary, from state to state.

STOP – BEFORE YOU RETURN THIS PRODUCT TO THE STORE

Save on gas and avoid the trip back to the store. Contact our Customer Service/Technical Support representatives for information and

trouble-shooting help. Call 1-800-7AIRGUN (1-800-724-7486) or find answers to frequently asked questions at www.crosman.com.

WARRANTY CLAIM

U.S. Customers- Contact Customer Service at 800-724-7486 or email us via www.crosman.com. You will be instructed where and how to send

your air gun in for repair under warranty or referred to one of our authorized service centers in your area.

Crosman Corporation

Attn: Warranty Dept.

7629 Route 5 & 20

Bloomfield, NY 14469

Include with your product a copy of your receipt and a brief description of the problem. Be sure to indicate your name, mailing address, email

address and telephone number. Allow 2-4 weeks for repairs. We recommend you use a method of shipping that provides you with a tracking

number and insurance options. Crosman is not liable for any damaged, lost or stolen merchandise during shipping.

Canadian Customers - Contact the Gravel Agency, in Quebec at 866- 662-4869.

Outside U.S. Customers: Please contact your point of purchase dealer/distributor. If you do not know your dealer/distributor, contact our

International Dept. for assistance at 585-657-6161 or email us via www.crosman.com.

CROSMAN, DUTY CALLS and GAMEFACE are trademarks of Crosman Corporation in the United States. MARINES AIRSOFT is a trademark of the

United States Marine Corps and is used under license.

Fig. 2

Fig. 3

GRIP SAFETY

SQUEEZE TO FIRE

Fig. 10

Fig. 9
