Do not let briquets
cover burner port holes.
BACK
OF
GRILL
4
3
BA
CK
OF
GRILL
BACK
PANEL
BACK
PANEL
1. Stand grill upside down and
attach back panel to legs and
brace with four bolts and nuts.
2. Facing back of grill, depress
buttons and snap leg extender
assembly into right legs and
wheel assembly (
) into left legs.
text facing
inward
IMPORTANT: Align tabs with
notches in legs.
1ST
2ND
Press
Notch
Tab
Text to
inside
Qty. 4
Qty. 4
1. Place 16 briquets onto briquet grate.
Arrange briquets as shown below.
2. Position Drip VapoRISER Bar as shown
and place above burner, resting on
supports at each end of grill bottom.
FRONT BACK
FRONT
BACK
Briquet Placement
