Parts List - Model 4638220
Key Qty. Description Part #
A 1 Warming Rack . . . . . . . . . . . . . . . 4152125
B 1 Cooking Grate . . . . . . . . . . . . . . . 4152741
C 1 Leg Extender Assembly . . . . . . . . 4154468
D 1 Handle . . . . . . . . . . . . . . . . . . . . . 4154488
E 1 Drip VapoRISER Bar . . . . . . . . . . 4156418
F 1 Wheel Assembly . . . . . . . . . . . . . 4158100
G - - - Briquets (1 bag) . . . . . . . . . . . . . . 4158125
H 1 Brace . . . . . . . . . . . . . . . . . . . . . . 4502155
I 1 Front Panel . . . . . . . . . . . . . . . . . 4503076
J 6 #10x1/2”, T-20, Self-Tap Screw . . 4080043
K 1 Briquet Grate . . . . . . . . . . . . . . . . 4151002
L 2 Valve Clip . . . . . . . . . . . . . . . . . . . 4156172
M 2 Casting Seat Bracket . . . . . . . . . . 4500222
N 2 Leg Assembly. . . . . . . . . . . . . . . . 4502156
O 1 Burner/Collector Assembly. . . . . . 4505069
P 1 Control Panel Assembly. . . . . . . . 4530074
Q 2 Control Knob . . . . . . . . . . . . . . . . 4154470
R 1 Grill Bottom . . . . . . . . . . . . . . . . . 4580149
S 1 Back Panel. . . . . . . . . . . . . . . . . . 4502064
T 8 #10x1-1/4” Self-Tap Screw. . . . . . 4080041
U 1 Side Shelf, Right . . . . . . . . . . . . . 4154459
V 4 Shelf Arm . . . . . . . . . . . . . . . . . . . 4502121
Key Qty. Description Part #
W 1 Side Shelf, Left. . . . . . . . . . . . . . . 4154456
X 1 Grill Lid. . . . . . . . . . . . . . . . . . . . . 4581964
Y 1 Logo Plate Assembly . . . . . . . . . . 4157147
Z 1 Grease Clip . . . . . . . . . . . . . . . . . 5156607
1 12’ Natural Gas Hose. . . . . . . . . . 4158033
1 Hardware Bag . . . . . . . . . . . . . . . 4253990
Replacement Ignition Module Bag . . . . . . . . 4506709
4 • 4638220
