Comtrol Building Custom Cables User Manual
Building custom cables

Building Custom Cables
1
Building Custom Cables
This section contains cabling information and how to build your own
custom cables for RocketPort controllers. To go to any of the following
topics, merely click on the topic:
DTE to DCE Straight-Through Cables
DTE to DTE Data-Only Null Modem Cables
DTE to DTE Control Loop-Back Cables
Building Custom Cables
Use this subsection if you want to build customized cables for the
Comtrol RocketPort controllers.
Usually you can buy the correct cables from distributors and electronics
stores for your controller. In some cases, your peripheral equipment
may need custom cables.
Check your equipment to understand what kind of cable to use, Data
Terminal Equipment (DTE) or Data Communications Equipment
(DCE). All Comtrol serial connectors are configured as DTE.
