7
Specifications
RocketPort PCI 422 Card Specification
Baud Rate:
RS-422 DTE/DCE 50 to 460.8K baud
Note: Baud rate is dependent upon hardware and operating system
configuration.
Bus interface PCI
Control by device driver:
Data bits
Parity
Stop bits 7 or 8
Odd, Even, None
1 or 2
Current consumption
+5V
850mA
Power consumption 4.25 W
Dimensions 4.9” by 4.2”
Heat output 14.49 BTU/Hr
I/O ports/expansion slot From 4 to 8
Interfaces RS-422
Mean time between failures (MTBF) 55.8 Years
Mode (hardware selectable) DTE or DCE
RocketPort cards/system 4
SMPTE standard 207M
Surge protection
Provides ESD surge protection
minimum of 10KV @ 200A for a
duration of 1 ns.
Interface Module Type
Mounting
Dimensions
Overall Dimensions
RS-422, 8-Port 3.37” x 2.69” 3.68” x 3.6” x 1.6”
