Page 22
22 - Specifications and Notices
RocketPort INFINITY User Guide: 2000465
Rev. E
Specifications and Notices
FCC Notices
Radio Frequency
Interference (RFI)
(FCC 15.105)
The RocketPort INFINITY has been tested and found to comply with the limits for
Class
B
digital devices pursuant to Part 15 of the FCC Rules when connected to:
•
Quad/octacable interface
•
Standard or surge interface boxes (4/8/16/32-port models)
The RocketPort INFINITY has been tested and found to comply with the limits for
Class
A
digital devices pursuant to Part 15 of the FCC Rules when connected to 16
or 32-port Rackmount interface boxes.
This equipment generates, uses, and can radiate radio frequency energy, and if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try and
correct the interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the distance between the equipment and receiver.
•
Connect the equipment to an outlet on a circuit different from that to which
the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
J1-17
J2-48
V+
J3-17
J2-55
V+
J1-18
J2-49
V+
J3-18
J2-56
V+
J1-19
J2-50
V+
J3-19
N/C
J1-20
N/C
J3-20
N/C
J1-21
N/C
J3-21
N/C
J1-22
J2-40
GND
J3-22
J2-34
GND
J1-23
J2-39
GND
J3-23
J2-33
GND
J1-24
J2-39
GND
J3-24
J2-32
GND
J1-25
J2-45
1B
RXCLK-
J3-25
J2-7
1B
RXCLK-
J1-26
J2-15
2B
RXDATA-
J3-26
J2-6
2B
RXDATA-
J1-27
J2-14
3B
RXDATB-
J3-27
J2-5
3B
RXDATB-
J1-28
J2-13
4B
RXCNVT-
J3-28
J2-4
4B
RXCNVT-
J1-29
N/C
J3-29
N/C
J1-30
J2-12
5B
TXDATB+
J3-30
J2-3
5B
TXDATB+
J1-31
J2-11
6B
TXDATA+
J3-31
J2-2
6B
TXDATA+
J1-32
J2-10
7B
TXCLK+
J3-32
J2-1
7B
TXCLK+
J1-33
J2-9
8B
TXCNVT+
J3-33
J2-60
8B
TXCNVT+
J1-34
J2-51
V+
J3-34
J2-57
V+
J1-35
J2-52
V+
J3-35
J2-58
V+
J1-36
J2-53
V+
J3-36
J2-59
V+
J1-37
N/C
J3-37
N/C
Ports 1-16 (Continued)
Ports 17-32 (Continued)
DB37-1
Source
LFH60
Dest
Pair
Signal
DB37-2
Source
LFH60
Dest
Pair
Signal
