Clippasafe 120 Pressure Fit Gate - Manual (Page 5)

Ensure the gate is in the open position by pressing the button (1) and
then lifting the latch (2), this will retract the screw adjuster on the gate.
To open the gate, lift it slightly. To close the gate, lift it slightly so that
the bottom sits back on the frame and push the handle down firmly.
Always check that the gate is closed and locked before leaving unattended.
Using the Gate E
Extensions F
1
2
Two extensions are available for this gate: a 7cm extension ‘F’ and a 14cm
extension ‘I’, these extensions can also be used together. With the 7cm
extension ‘F’ this gate is suitable for openings between 80.5cm and 87.5cm,
with the 14cm extension ‘I’ this gate is suitable for openings between
87.5cm and 94.5cm. With both the 7cm and the 14cm extensions ‘F’ & ‘I’,
this gate is suitable for openings between 94.5cm and 102cm.
x 1 F x 2 C x 1 I x 2 H x 2 J x 1 K
