-45-
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1 603-0172 Pivot Arm, Double Pulley 1
2 603-0181A Plate Assembly, Mounting 1
3 703-2463 Arm, Idler 1
4 710-0520 Screw, Hex Cap, 3/8-16 x 1.5 GR5 1
5 710-0923 Screw, Hex Cap, 5/8-18 x 3.0 GR5 1
6 710-1010 Screw, Hex Cap, 1/2-20 x 3.0 GR8 1
7 710-1260 Screw, Hx Wsh Hd Tapp, 5/16-18 x .75 8
8 710-1336 Bolt, Spindle, 3/4-16 x 4.25 2
9 712-0239 Nut, Hex Center Lock, 1/2-20 1
10 712-0431 Nut, Hex Flange Lock, 3/8-16 1
11 712-3078 Nut, Hex Flange, 3/4-16 2
12 716-3020 Snap Ring, Internal 2
13 721-3018 Seal, Oil, 1.25 x 1.874 x .25 4
14 732-0262 Spring, Extension, .88 x 6.12 1
15 732-3115 Spring, Extension, 1.25 x 8.15 1
16 736-0100 Washer, Flat, .531 x 1.25 x .036 1
17 736-0179 Washer, Flat, .531 x 1.25 x .100 1
18 736-0290 Washer, Flat, .63 x 1.0 x .063 Hdn 1
19 737-3000 Fitting, 3/16 Drive Lube 3
20 741-0338 Bearing, Flange, 3/4 ID x .53 Lg 2
21 741-0524 Bearing, Ball, .62 ID x 1.57 OD 2
22 741-3028 Cone, Bearing 4
23 741-3029 Cup, Bearing 4
24 741-3031 Spacer, Bearing 2
25 748-3065 Spacer, Deck Spindle 4
26 750-0656 Spacer, Idlr Brkt .50 ID x .75 OD x 2.25 1
27 750-3132 Spacer, Pulley, .635 ID x .88 OD x 1.25 1
28 750-3190 Spacer, Bearing, .780 x .963 x .7777 2
29 750-3191 Spacer, Bearing, 1.615 x 1.86 x .8427 2
30 754-3029 Belt, Spindle, A-Section x 59 Lg 1
31 754-3055A Belt, PTO, B-Section x 112.4 Lg 1
32 756-0627 Pulley, Flat Idler, 3.5 OD 1
33 756-3070 Pulley, Double 1
34 756-3089 V-Pulley, 4.0 Dia 2
35 759-3829 Blade, 3 In One, 19.38 Lg 2
36 918-3129 Spindle Assy, (Incl. Ref #13, 22- 24, 28-29) 2
37 731-1643A Plug, Mulch 1
38 710-0597 Screw, Hex Cap, 1/4-20 x 1.0 GR5 1
39 712-3006 Nut, Hex, 1/4-20 1
40 712-3087 Nut, Wing, 1/4-20 1
41 736-0173 Washer, Flat, .28 x .74 x .063 1
38” SPINDLE ASSEMBLY
