-32-
STARTER COMPONENTS
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1 ME-185-2659 Frame, Starter 1
2 ME-185-2661 Holder, Brush 1
3 ME-185-2662 Spring, Brush 4
4 ME-185-2664 Insulator 1
5 ME-185-2965 Hose, Drain 1
6 ME-185-263 Bearing, Oilless 1
7 ME-185-6383 Frame Assy, End (Incl. Ref #6) 1
8 ME-185-2660 Bolt, Through 2
9 ME-185-2367 Nut 1
10 ME-870-0465 Nut 1
11 ME-185-2381 Washer, Spring 1
12 ME-185-6381 Armature, Starter 1
13 ME-185-2658 Switch, Magnetic 1
14 ME-185-6382 Clutch 1
15 ME-185-6385 Nut, Pinion Stop 2
16 ME-185-6386 Ring, Snap 1
17 ME-185-2334 Nut 2
18 ME-185-6387 Washer, Plate 1
19 ME-185-2656 Lever, Starter Drive 1
20 ME-185-2706 Housing, Starter 1
21 ME-185-6384 Bearing, Oilless 1
ME-191-2107 Starter Assembly 1
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
