-11-
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
A HG-2510050 Kit, Check Valve 1
B HG-2510034 Kit, Orificed Check Valve 1
C HG-2513009 Kit, Cylinder Block 2
D HG-2510011 Kit, Charge Relief Valve 1
E HG-2513027 Kit, Charge Pump 1
1 HG-50185 Shaft, Pump 1
2 HG-2003016* Ring, Retaining 2
3 HG-2003043 Bearing, Ball 1
4 HG-2003018* Spacer 1
5 HG-9008000-0128* Seal, Lip 1
6 HG-2003052* Ring, Retaining 1
7 HG-2513036 Housing Assy (Incl. Ref #8, 14, & 18) 1
8 HG-2003009 Bearing, Journal 1
9 HG-9008000-0126* Seal, Lip 1
10 HG-2003005 Arm, Trunnion 1
11 HG-2000015 Guide, Slot 1
12 HG-2003087 Swashplate 1
13 HG-2003023 Bearing, Cradle 2
14 HG-9004820-2536 Pin, Leveler 1
15 HG-2003091 Leveler, Swashplate 1
16 HG-2003092 Spring, Leveler 1
17 HG-2003044 Bearing, Thrust 2
18 HG-2003071 Bearing, Journal 1
19 HG-9005110-4400 Plug 1
20 HG-9004800-2506 Pin 2
21 HG-9005110-8700 Plug 1
22 HG-2003034 Shaft, Motor 1
23 HG-2003060* Gasket, Center Section 1
24 HG-2513037 Center Section Assy (Incl. Ref #25, 26) 1
25 HG-2003071 Bearing, Journal 1
26 HG-2003045 Bearing, Needle 1
27 HG-9005001-0600 Plug, Pipe 1
28 HG-9004201-3700* O-Ring 3
29 HG-9007314-0808 Screw, Socket Hd 8
30 HG-9005110-5600 Plug w/Ring 2
31 HG-9004101-1340* O-Ring 1
32 HG-J1041008 Gerotor Assy 1
33 HG-9007375-0038 Screw, Socket Hd 2
34 Not Used In This Application
* HG-2513013 Kit, Overhaul Seal 1
HYDROSTATIC PUMP
* Indicates Parts In Overhaul Seal Kit
