-43-
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1 603-0181A Plate Assembly, Mounting 1
2 603-0199 Handle, Tension 1
3 603-0200 Bracket, Front Lift 1
4 603-0408A Deck Assembly, 38” 1
777S30010 Graphic, Danger Top/RH Deck 1
777S30014 Graphic, Tension Lever 1
777S30018 Graphic, Safety Top/LH Deck 1
777S30012 Graphic, Assembly Chute 1
5 703-1693 Bracket, Hinge Mounting 1
6 703-2559 Bracket, Handle Stop 1
7 703-3237 Shield, RH Pulley 1
8 703-2945 Shield, LH Pulley 1
9 710-0751 Screw, Hex Cap, 1/4-20 x .62 GR5 2
10 710-1260A Screw, Hx Wsh Hd Tapp, 5/16-18 x .75 3
11 710-3008 Screw, Hex Cap, 5/16-18 x .75 GR5 2
12 710-3178 Bolt, Carriage, 3/8-16 x .75 3
13 711-0792 Pin, Hinge, .25 Dia x 6.75 Lg 1
14 711-3314 Pin, Roller, 1/2 Dia x 7.31 Lg 1
15 712-0431 Nut, Hex Flange Lock, 3/8-16 10
16 712-3004A Nut, Hex Flange Lock, 5/16-18 GR5 5
17 712-3006 Nut, Hex, 1/4-20 4
18 712-3048 Nut, Hex Jam, 1/2-13 GR5 2
19 712-3083 Nut, Hex Insert Lock, 1/2-13 2
20 714-3004 Pin, Cotter, 3/32 x 1.25 1
21 715-3003 Pin, Spirol Spring, 3/16 x .75 2
22 726-0106 Cap, Speed Nut 1
23 731-1032 Deflector Assy, (Incl. Ref #5, 13, 22, 26) 1
24 731-3005 Roller 1
25 732-0262 Spring, Extension, .88 OD x 6.12 1
26 732-0602 Spring, Torsion 1
27 732-3115 Spring, Extension, 1.25 OD x 8.15 1
28 732-3127 Spring, Compression 2
29 734-0973 Wheel, Deck, 5 in. Dia 2
30 736-0270 Washer, Bell, .265 x .75 x .062 4
31 736-0272 Washer, Flat, .510 x 1.0 x .060 4
32 736-0921 Washer, Lock, 1/2 2
33 738-0143 Bolt, Shoulder, .498 Dia x .340 Lg 1
34 738-507B Bolt, Shoulder, .50 Dia x .434 Lg 2
35 738-0533 Bolt, Shoulder, .498 Dia x 1.64 Lg 2
36 738-0572 Bolt, Shoulder, .375 Dia x 1.16 Lg 2
37 747-3172 Rod, Front Lift 1
38 747-3188 Pin, Mower Support 2
39 777S30145 Graphic, Danger 1
40 703-1890 Wheel, Deck w/Fitting 2
737-0280 Lube Fitting 2
41 738-3056 Bolt, Shoulder, 1/2 x 2.5 2
42 736-0105 Washer, Bell, .401 x .870 x .063 2
38” DECK ASSEMBLY
