Hydro transmission – Cub Cadet 2146 User Manual
Page 11

-9-
REF.
NO.
PART
NUMBER
DESCRIPTION
QTY.
1
611-3008
Axle Assy, LH, 11.9" Lg
1
2
716-3015
Ring, Inverted Retainer
2
3
721-3020A
Seal, Oil
2
4
741-3033A
Bearing 2
5
716-3018
Ring, External Retaining
2
6
619-3025
Housing, LH Axle
1
7
710-1008
Screw, Hex L-Wash Tap, 3/8-16 x 1.88 16
8
727-3085
Dipstick, OIl
1
9
715-3045
Bushing, Dowel
4
10
619-3037B
Housing, LH Differential
1
11
710-0606
Screw, Hex Cap, 1/4-20 x 1.5
2
12
736-0463
Washer, Flat, .25 x .62 x .052
4
13
710-0788
Screw, Hex Wash Hd Tap, 1/4-20 x 1.0 15
14
710-1346
Screw, Plug, M14 x 1.5 x .827
1
15
715-3045
Bushing, Dowel
2
16
741-0361
Bearing, Ball
3
17
750-3133
Spacer, .757 ID x 1.0 OD x 1.46
1
18
717-3388
Gear, 27T Drive
1
19
717-3374
Shaft, Drive
1
20
717-3347
Gear, 36T Bevel
1
21
717-3391
Gear, 16T Spur
1
22
750-3134
Spacer, .885 ID x 1.125 OD x 1.4
1
23
717-3387
Gear, 18T Shift
1
24
718-3039
Collar, Drive
1
25
732-3113
Spring, Compression, 1.015 ID x 1.6
1
26
711-3379A
Shaft, Shifter
1
27
741-3057
Bearing, Ball, .787 x 1.85 x .551
3
28
717-3392
Gear, 42T Spur
1
29
717-3346
Shaft, 9T Output
1
30
741-3037
Bearing, Ball
2
31
710-0151
Screw, Hex Cap, 3/8-24 x 2.0
4
32
619-3013
Cover,Differential 2
33
736-0423
Washer, Flat, 1.0 x 1.56 x .010 Thk
AR
34
736-0431
Washer, Flat, 1.0 x 1.56 x .015 Thk
AR
35
736-0424
Washer, Flat, 1.0 x 1.56 x .020 Thk
AR
36
736-0420
Washer, Flat, 1.0 x 1.56 x .040 Thk
AR
37
717-1159
Gear, 60T Bull
1
38
717-1119
Gear, 14T Differential Side
2
39
717-1190
Block, Differential Thrust
4
40
717-1120
Gear, 10T Differential Pinion
4
41
717-1178
Shaft, Cross
2
42
717-1173
Shaft, Cross, .50 OD x 3.485 Lg
1
43
712-3054
Nut, Hex Lock, 3/8-24
4
44
721-3008
O-Ring, 3/8 ID x 1/2 OD
1
45
618-3084
Yoke Assy, Shift (Incl. Ref #44)
1
46
619-3036A
Housing, RH Differential
1
47
712-0291
Nut, Hex Center Lock, 1/4-20
2
48
721-3029
Seal, Shift Shaft
1
49
761-3019
Drum, Brake
1
50
732-3077
Spring, Brake
1
51
761-3020
Shoe, Brake
2
52
732-0152
Spring, Compression
1
53
703-2191
Arm, Brake
1
54
618-3060
Plate, Brake
1
55
761-3028
Actuator, Brake Shoe
1
56
710-3262
Screw, Low Hd Cap, 3/8-16 x .75
1
57
611-3009
Axle Assy, RH, 15.6 Lg
1
58
619-3024
Housing, Axle, RH
1
59
717-1180
Block, Differential Pinion
1
REF.
NO.
PART
NUMBER
DESCRIPTION
QTY.
HYDRO TRANSMISSION
