Turbomachinery Package Specification Taurus 70 Compressor Set and Mechanical Drive
Table 12. Air Inlet System Specifications
Air Inlet System
Pressure Drop Less Than 102 mm (4 in.) H2O with a Clean Air Filter
Ducting Loads Loads Exceeding 91 kg (200 lb) Should Not Be
Applied In Any Direction on any component
Prefilter and Barrier Inlet Air Filter
Air Flow 1274 m 3 /min (45 000 cfm)
Approximate Measurements
Height 229 cm (90.0 in.)
Width 281 cm (110.62 in.)
Length 167 cm (65.8 in.)
Weight 1077 kg (2375 lb)
Pressure Drop
Clean 44 mm (1.75 in.) water
Fouled 127 mm (5 in.) water
Self-Cleaning Barrier Type Air Filter
Fluid Clean-Dry Air
Air Quality See Note (a)
Minimum/Maximum Regulated Pressure Range 552 to 758 kPag (80 to 100 psig)
Intermittent Flow Rate (Est.) 0.25 nm 3 /min (9 scfm)
Pressure Drop
Clean 35 mm (1.5 in.) water
Fouled 76 mm (3.0 in.) water
Air Flow 21.2 m 3 /min (45 000 cfm)
Approximate Measurements (Without Leg Kit)
Height 274 cm (108 in.)
Width 310 cm (122 in.)
Length 465 cm (183 in.)
Weight 4227 kg (9300 lb) with filter elements
Marine / Offshore High Velocity Type Air Filter
Pressure Drop (Clean), HVL 48 mm (1.9 in.) water
Pressure Drop (Clean), HVX 53 mm (2.1 in.) water
Air Flow 21.2 m3/sec (45,000 cfm)
Approximate Measurements
Height 206 cm (81.1 in.)
Width 261 cm (102.8 in.)
Length 153 cm (60.4 in.)
Weight 1021 kg (2250 lb) with filter elements
Offshore / Coastal Medium Velocity Type Air Filter
Pressure Drop (Clean) - 3 stage 34 mm (1.34 in.) water
Pressure Drop (Clean) - 4 stage 54 mm (2.14 in.) water
Air Flow 21.2 m3/sec (45,000 cfm)
Approximate Measurements
Height 280 cm (110.3 in.)
Width 341 cm (134.3 in.)
Length 312 cm (122.7 in.)
Weight 2435 kg (5369 lb) with filter elements (4 stage)
© 2009 Solar Turbines Incorporated. All rights reserved. TPS70CSMD/309
58
