Turbomachinery Package Specification
Taurus
70 Compressor Set and Mechanical Drive
CO
2
Fire Cylinder Cabinets
Fire Cylinder Cabinet, Main
Height
213 cm (84 in.)
Width
165 cm (65 in.)
Depth
48 cm (19 in.)
Approximate Cabinet Weight
454 kg (1000 lb), Without Cylinders
Approximate Cylinder Weight
544 kg (1200 lb)
Fire Cylinder Cabinet, Extended Release
Height
213 cm (78 in.)
Width
165 cm (65 in.)
Depth
48 cm (19 in.)
Approximate Cabinet Weight
454 kg (1000 lb), Without Cylinders
Approximate Cylinder Weight
544 kg (1200 lb)
Water Mist Fire Cylinder Cabinet
Fire Cylinder Cabinet
Height
241 cm (95 in.)
Width
165 cm (65 in.)
Depth
99 cm (39 in.)
Approximate Cabinet Weight
454 kg (1000 lb), Without Cylinders
Approximate Cylinder Weight
544 kg (1200 lb)
Construction Materials
Enclosure Housing
Carbon Steel
Enclosure Door Hardware
316L Stainless Steel
Fire Cylinder Cabinets
Carbon Steel
316L Stainless Steel (Optional)
Dust and Moisture Protection System
Carbon Steel
316L Stainless Steel (Optional)
Solar’s Applicable Engineering Specifications
ES 1593
Guidelines for NEC Compliance of Solar Product Lines: Class I, Group D, Division 1
and Division 2
ES 1762
Standards and Practices for Electrical Systems for Gas Turbine Packages Installed In
Hazardous Areas (CENELEC/IEC Standards – European ATEX Directive 94/9/EC)
Solar’s Applicable Product Information Letters
PIL 054
OSHA Noise Requirements
PIL 058
Package Sound Levels
PIL 150
Fire and Gas Detection and Control System
Notes
:
(a)
The estimated A-weighted sound pressure level is 85 dBA at a distance of 1 m (3 ft) from the
enclosure wall and a height of 1.5 m (5 ft). This value is based on an average of multiple
readings taken around the perimeter of the package. This level applies only to the enclosed
equipment and is exclusive of sound generated by piping, unenclosed driven equipment (if
applicable), other equipment, reflected sound, or contributing site conditions. Sound levels at
a specific site will depend on existing walls, barriers, equipment in close proximity, multiple
units, and other installation considerations.
© 2009 Solar Turbines Incorporated. All rights reserved.
TPS70CSMD/309
53
