Turbomachinery Package Specification

Taurus

70 Compressor Set and Mechanical Drive

Single-Phase Lighting and Space Heater Voltage

Optional Package Lighting and Space Heater
Voltage Ratings

120, 220, 230, or 240 VAC, 50 Hz or 60 Hz

Ingress Protection (IP) Ratings

On-skid Junction Boxes

IP56 to IP66

Control Console

IP50

Battery Charger, NEC

IP22

Battery Charger, CE

IP31

Solar’s Applicable Engineering Specifications

ES 9-56

Fusion Welding

ES 9-58

Standard Paint Program – Turbo Machinery

ES 1593

Guidelines for NEC Compliance of Solar’s Product Lines: Class I, Group D, Division 1
and Division 2

ES 1762

Standards and Practices for Electrical Systems for Gas Turbine Packages Installed In
Hazardous Areas (CENELEC/IEC Standards – European ATEX Directive 94/9/EC)

ES 2201

Auxiliary Air

ES 2231

Standards and Practices for The Design and Installation of Cable Channels and TC
Rated Cables Installed In Class 1, Division 2 Hazardous Areas

Solar’s Applicable Product Information Letters
PIL 127

Product Certification

PIL 140

Dry Gas Face Seals for Solar Compressors

Notes:

(a)

All package piping is fabricated from 316L stainless steel with the exception of lube oil vent
lines and any piping welded directly to a carbon steel lube oil tank or tank cover.

TPS70CSMD/309
