Turbomachinery Package Specification

Taurus

70 Compressor Set and Mechanical Drive

Main Lube Oil Duplex Filters

Type Self-Supporting

Pedestal

Duplex Filters

10 Micron

Certification

ASME, Section VIII, Division 1

Backup Lube Oil Pump Filter

Type Bowl

Filter

Minimum/Maximum Operating Temperatures

-54 to 135°C (-65 to 275°F)

Simplex Filter

β X > 75 Micron

Lube Oil Vent Coalescer

Type

Air/Oil Mist Eliminator

Maximum Working Temperature

93°C (200°F)

Orientation Vertical
Performance

100% removal of all droplets greater than 3
microns and 99.5% removal of all droplets less
than 3 microns.

Certification

ASME, Division 1

Approximate Dimensions (Height x Diameter)

230 cm x 84 cm (90.4 in. x 33 in.)

Approximate Weight

576 kg (1270 lb)

Lube Oil Vent Flame Arrestor

Orientation

Vertical, See Note (f)

Approximate Dimensions (Height x Diameter)

56 cm x 26 cm (22 in. x 10.3 in.)

Approximate Weight

26 kg (58 lb)

Strainers

Tank Fill

20 mesh

Gearbox Breather Vent (If Applicable)

40 mesh

Gas Producer Start-Up Strainer

70 Micron, See Note (g)

Gearbox Start-Up Strainer (If Applicable)

70 Micron, See Note (g)

Compressor Driven End Start-Up Strainer

70 Micron, See Note (g)

Compressor Exciter End Start-Up Strainer

70 Micron, See Note (g)

Lube Oil

Viscosity Grade ISO VG 32 (C32)

Use When Ambient Temperature is <43°C (110°F)

Viscosity Grade ISO VG 46 (C46)

Use When Ambient Temperature is >43°C (110°F)

Pour Point

Must Be At Least 6°C (11°F) Below The Lowest
Ambient Temperature)

Lube Oil Tank Capacity

4713 L (1245 gal), See Note (h)

Weight

3946 kg (8700 lb)

Construction Materials

Piping, Manifolds, and Tubing

316L Stainless Steel

Lube Oil Tank and Tank Covers
