Page 8
Table 5A — Electrical Data (3 Ph/60 Hz)
UNIT
UNIT
COMPR
FAN MOTORS (Single Phase)
Model
Volts
MCA
ICF
MOCP
(Fuse)
RLA
LRA
Total
Fans
FLA (ea)
Fan No.
kW
Nameplate
Supplied*
Min
Max
1
2
38AE012
501
208-230
187
253
62.5
178
100
43.6
170
2
4.3
3.7
1.41
201
380
342
418
35.0
101
50
24.0
93
4.3
3.7
601
460
414
528
29.1
81
40
20.0
77
2.3
1.9
101
575
518
660
22.8
67
35
15.7
62
1.8
1.8
38AE014
501
208-230
187
253
69.3
199
100
49.3
191
2
4.3
3.7
1.41
201
380
342
418
38.0
112
60
26.5
104
4.3
3.7
601
460
414
528
31.7
84
50
22.1
80
2.3
1.9
101
575
518
660
25.6
73
40
17.9
69
1.8
1.8
38AE016
501
208-230
187
253
87.5
274
125
63.6
266
2
4.3
3.7
1.41
201
380
342
418
49.3
153
80
36.0
145
4.3
3.7
601
460
414
528
40.7
124
60
29.3
120
2.3
1.9
101
575
518
660
33.0
100
50
23.8
96
1.8
1.8
38AKS024
501
208-230
187
254
93.4
353
150
67.9
345
2
4.3
3.7
1.41
201
380
342
418
49.7
199
80
34.6
191
4.3
3.7
601
460
414
508
48.1
177
80
34.7
173
2.3
1.9
101
575
518
632
40.1
124
60
28.8
120
1.8
1.8
Table 5B — Electrical Data (3 Ph/50 Hz)
UNIT
UNIT
COMPR
FAN MOTORS 230 v (Single Phase)
Model
Volts
MCA
ICF
MOCP
(Fuse)
RLA
LRA
Total
Fans
FLA (ea)
Fan No.
kW
Nameplate
Supplied*
Min
Max
1
2
38AE012
803
230
198
264
47.5
134
75
32.9
128
2
2.9
3.5
1.20
903
400
342
457
31.4
80
50
20.0
74
38AE014
803
230
198
264
51.0
149
75
35.7
143
2
2.9
3.5
1.20
903
400
342
457
34.0
89
50
22.1
83
38AE016
803
230
198
264
66.9
206
100
47.9
200
2
2.9
3.5
1.20
903
400
342
457
43.0
121
60
29.3
115
38AKS024
803
230
198
254
91.8
213
150
67.9
207
2
2.9
3.5
1.20
303
346
311
380
51.5
121
80
33.3
115
903
400
342
440
50.2
179
80
34.6
173
LEGEND
FLA
— Full Load Amps (Fan Motors)
ICF
— Maximum Instantaneous Current Flow during start-up (LRA of compressor plus total FLA of fan motors)
kW
— Total Fan Motor Input (kilowatts)
LRA
— Locked Rotor Amps
MCA
— Minimum Circuit Amps per NEC (U.S.A.), Section 430-24
MOCP — Maximum Overcurrent Protection (amps)
RLA
— Rated Load Amps (Compressor)
*Units are suitable for use on electrical systems where voltage supplied to the unit terminals is not below or above
the listed limits.
NOTES:
1. The MCA and MOCP values are calculated in accordance with the National Electrical Code (NEC) article 440
(U.S.A. standard).
2. Motor RLA and LRA values are established in accordance with Underwriters’ Laboratories (UL) Standard 1995
(U.S.A. standard).
LEGEND
C
— Compressor Contactor
R
—
Relay
HD
— Heating Device
Factory Wiring
IFC
— Indoor-Fan Contactor
Field Wiring
LLSV — Liquid Line Solenoid Valve
NOTES:
1. Combination LLSV plus IFC va should not exceed 30 va.
2. Do not exceed 5 va (24 vac) per coil.
3. If va values shown in Notes 1 and 2 must be exceeded, use
accessory relay transformer package 38AE900001.
Fig. 7 — Remote Thermostat Wiring
8
