Using the SPA500S Attendant Console
Connecting the SPA500S Attendant Console to the IP Phone
Cisco Small Business Pro IP Phone SPA50X User Guide (SIP)
83
6
!
CAUTION
Do not plug a telephone line cord into the AUX port. Use only the auxiliary cable
provided with the SPA500S.
STEP 7
Locate the AUX OUT port on the back of the first SPA500S. Connect one end of
the auxiliary cable to this port.
STEP 8
Locate the AUX IN port on the back of the second SPA500S. Connect the other
end of the auxiliary cable to this port.
STEP 9
Route the auxiliary cable inside the cable slot. The SPA500S is powered by the
auxiliary cable with the IP phone; no additional power source is required.
STEP 10
Attach the appropriate desktop stands to each unit.
