Page 347

Black plate (41,1)

Cadillac SRX Owner Manual - 2010

Vehicle Care

9-41

8. Press a new bulb into the

socket, insert it into the taillamp
assembly and turn the bulb
socket clockwise until it clicks.

9. Reinstall the taillamp assembly

and tighten the screws.

10. Reinstall the taillamp cover by

snapping it into place.

11. Push the push pin to secure

the taillamp cover.

Back-Up Lamps

To replace one of these bulbs:

1. Open the liftgate. See Liftgate

A. Push Pin

B. Taillamp Cover

2. Pull on push pin (A) to release

the taillamp cover (B).

3. Remove the taillamp cover from

the lamp assembly by pulling
rearward from the top to
unfasten from snap tabs.

4. Remove the two screws from the

taillamp assembly.

5. Pull the taillamp assembly

straight back to remove.
