Cadillac SRX 2010 - Manual (Page 258)

Black plate (14,1) Cadillac SRX Owner Manual - 2010
8-14 Driving and Operating
Example 2
A. Vehicle Capacity Weight for
Example 2 = 453 kg
(1,000 lbs).
B. Subtract Occupant
Weight @ 68 kg
(150 lbs) × 5 = 340 kg
(750 lbs).
C. Available Cargo
Weight = 113 kg (250 lbs).
Example 3
A. Vehicle Capacity Weight for
Example 3 = 453 kg
(1,000 lbs).
B. Subtract Occupant
Weight @ 91 kg (200 lbs)
× 5 = 453 kg (1,000 lbs).
C. Available Cargo
Weight = 0 kg (0 lbs).
Refer to the vehicle's Tire and
Loading Information label for
specific information about the
vehicle's capacity weight and
seating positions. The combined
weight of the driver, passengers,
and cargo should never exceed
the vehicle's capacity weight.
Certification Label
Label Example
A vehicle specific Certification/
Tire label is attached to the rear
edge of the driver's door. The
label shows the size of the
vehicle's original tires and the
