Black plate (36,1)

Cadillac SRX Owner Manual - 2010

9-36

Vehicle Care

Up–Level Headlamp Assembly
(Front View Driver Side)

A. High/Low‐Beam Headlamp

(To be replaced at dealer only)

B. Daytime Running Lamp (DRL)

C. Turn Signal Lamp

Up–Level Headlamp Assembly
(Rear View Driver Side)

A. High/Low‐Beam Headlamp

(To be replaced at dealer only)

B. Daytime Running Lamp (DRL)

C. Turn Signal Lamp

Driver Side

The removal of the underhood
electrical center is required for the
replacement of one of these bulbs:

1. Open the hood. See Hood on

page 9‑5.

{

WARNING

Liquids from environment or
spillage and/or tools placed on
top of or used in the underhood
electrical center while the cover
is removed can pose a risk of
electrical shock/burn to anyone in
the vicinity. These conditions can
also cause damage to electrical
components on the vehicle. Keep
liquids and tools away from the
underhood electrical center when
the cover is removed.
