Vehicle Care
9-7
A. Engine Air Cleaner/Filter on
B. Power Steering Reservoir and
Cap. See Power Steering Fluid
on page 9‑22.
C. Engine Oil Fill Cap. See Engine
D. Engine Oil Dipstick (Out of
View). See Engine Oil on
page 9‑10.
E. Brake Master Cylinder
Reservoir. See Brakes on
page 9‑24.
F.
Battery (Out of View). See
Battery on page 9‑27.
G. Engine Coolant Surge Tank and
Pressure Cap. See Engine
Coolant on page 9‑17.
H. Remote Positive (+) Terminal.
See Jump Starting on
page 9‑101.
I.
Remote Negative (−) Terminal
(Out of View). See Jump
Starting on page 9‑101.
J.
Engine Compartment Fuse
Block on page 9‑45.
K. Windshield Washer Fluid
Reservoir. See Washer Fluid on
page 9‑23.
