U S I N G Y O U R R A N G E
Replacing the storage drawer:
1. Fit
ends of drawer slide rails into the
drawer guides on both sides of opening.
2. Lift drawer front and push in until metal
stops on drawer slide rails clear white
stops on drawer guides.
Lift drawer front
again to clear second stop and slide
drawer closed.
The anti-tip bracket
The range will not tip during normal use. However, tipping can occur if you apply too much
force or weight to the open door without the anti-tip bracket properly secured.
^WARNING
Personal Injury Hazard
•To reduce risk of range tipping over, secure range with a properly
installed anti-tip bracket supplied with range or an optional wall-
mounted anti-tip bracket kit.
• If range is moved for cleaning or service, check that anti-tip bracket
is engaged before using range.
Failure to follow the above precautions could result in personal injury.
To verify the anti-tip bracket
is engaged (if you have a floor
bracket):
• Remove the storage drawer. (See page 19.)
• Look to see if the anti-tip bracket is
attached to floor with screws.
• Make sure one rear leveling leg is positioned
under the anti-tip bracket.
• See Installation Instructions for further details.
To verify the anti-tip bracket
is engaged (if you have a wall
bracket):
• Look to see if the anti-tip bracket is at­
tached with screws to the wall behind the
control panel.
■ Make sure the cable on the back of the
range is secured by the two hooks on the
bracket.
• Cable must be unhooked from wall bracket
to move range for cleaning or service.
Reconnect cable before using range.
• See Installation Instructions for further details.
Floor bracket
'Cable
(attached
to rear of
control
panel)
20
