Mini Fuses Usage
9
Fuel
Injectors – Even
10 Fuel Injectors – Odd
11 Cooling Fan Relay
14
Manifold Air Flow/
Chassis Control
15 Ignition
16 Run/Crank IP
17
Sensing Diagnostic
Module/Ignition
18 Run/Crank Body
19
Transmission
Control Module/
Ignition
20
Engine Control
Module/Ignition
31
Outside Rearview
Mirror
32
Canister Vent
Solenoid
Mini Fuses Usage
33
Body Control
Module #6
34 Sunroof
35 Front Heated Seats
38 Washer Pump Front
40
Antilock Brake
System Valves
46
HID Headlamp –
Left Front
47
HID Headlamp –
Right Front
50 Fog Lamps
51 Horn
52 Spare
55
High Beam
Headlamp – Right
Front
56
High Beam
Headlamp – Left
Front
61 Heated Mirror
Mini Relays Usage
K26 Powertrain
K50 Run/Crank
K55 Rear Defog
K612 Cooling Fan High
K614 Cooling Fan Control
Micro
Relays
Usage
K61 Starter
K69 Wiper Control
K613 Cooling Fan Low
K617
Air Conditioning
Compressor Clutch
K619 Wiper Speed
K627
High Intensity
Discharge
Headlamps
K632
Brake
Vacuum Pump
