Underhood Fuse Block
The underhood fuse block
is located next to the
engine on the passenger’s
side of the vehicle. For
more information on
location, see Engine
Compartment Overview
on page 6-12.
To access the fuses, push in the tab located at the end
of the fuse block cover. Then lift the cover open.
Fuses Usage
1
Anti-Lock Brake System, Magnetic
Ride Control
2 Horn
3
Adaptive Cruise Control (ACC),
Transmission Controls
4 Windshield Wipers
5 Stop/Back-Up Lamps
6 Oxygen Sensor
7 Battery 5
8 Parking Lamps
9 Electronic Throttle Control
6-83
