4-3
LANVIEW LEDs
The functions of the Ethernet Receive LEDs are listed in Table 4-4.
The functions of the Ethernet Transmit LEDs are listed in Table 4-5.
The function of the Link LEDs is listed in Table 4-6.
Table 4-4. Ethernet Receive LEDs
LED Color State
Green Link, No activity
Yellow (Flashing) Link, Activity (Flashing rate indicates rate of
activity)
Off No link, No activity
Table 4-5. Ethernet Transmit LEDs
LED Color State
Green (Flashing) Activity (Flashing rate indicates rate of activity)
Yellow (Flashing) Port in standby state
Off No activity
Table 4-6. Link LEDs
LED Color State
Green Link
Off No link
