2-5
Installing the Modules
The Reset Switch
The Reset switch is located on the front panel, under the top plastic tab, as shown
in Figure 2-4. (Under the right-side tab on the 9E138-36.) It serves two functions:
• Pressing the Reset switch twice within three seconds causes the processor
(i960) to reset.
• Pressing and holding the switch on for three or more seconds causes the
module to shutdown. Pressing and holding again for three seconds restarts the
module.
SNMP management may be used to disable this switch to enhance module
security.
Figure 2-4. The Reset Switch
SMB CPU
Reset Switch
