Installing the Modules
2-6
User-Accessible Components
Figure 2-5 shows the various components that are accessible to the user. These
consist of an eight-position dip switch (explained in the next section), replaceable
PROMs and sockets for RAM. These will be used for future upgrades.
Instructions for installing the components will be supplied with the upgrade kit.
Figure 2-5. User-Accessible Components
SMB-1
PROM
i960
Processor
Shared DRAM
Socket
Flash SIMM
Socket
Boot PROM
Local DRAM
Socket
DIP Switch
