10
M-31 Wireless Control Module Operation
The wireless control module M-31 consists of a transmitter equipped with two buttons for fog
on and off, and a signal receiver pre-attached to the panel of each M-31.
1
2 3
4
5
* Transmitter:
With the transmitter it is possible to emit fog via radio over a distance of up to 50 meters. The
transmitter is compatible to any receiver of the M-31 and can control an unlimited number of
machines in parallel.
Press the button “A”, to emit fog. The button “A” has the same function as the button
VOLUME on the LCD control panel, i.e. the fog output depends on the setting of menu item
»Volume Out«. The display indicates »Volume« (High or Medium or Low output). To stop the
fog output, press the button “B”.
1. 5-pin XLR
(Cable Length：2m)
2. LCD-Dispaly
3. Fuction Buttons
4. Transmitter
5. Receiver
