-Menu settings with the button FUNCTION
-Setting time intervals for timer operation
Press the button FUNCTION until the display indicates "Interval Set”. Use the
buttons UP and DOWN to adjust the intervals between the individual fog outputs in
timer mode within the range of 10 and 300 seconds.
-Setting the output duration for timer operation
Press the button FUNCTION until the display indicates "Duration Set”. Use the
buttons UP and DOWN to adjust the duration of the fog outputs in timer mode within
the range of 10 and 100 seconds.
-Setting the fog output volume
Press the button FUNCTION until the display indicates "Volume Out”. Use the
buttons UP and DOWN to select one of four default settings for the fog output volume:
.
• Nonstop Burst -- The machine will continuously produce low fog. The output volume
is automatically adjusted by the machine based on the operating temperature.
• High Volume -- about 60 % output volume
• Medium Volume -- about 52 % output volume
• Low Volume -- about 35 % output volume
* When set to "Nonstop Burst" or "Low Volume", the machine will continuously produce low fog.
However, the setting "Nonstop Burst" will produce the higher output volume.
* Please suspend the operation for 5 minutes before switching from the setting "Nonstop Burst" to the
setting "High Volume" or "Medium Volume".
-Setting the DMX512 address
Press the button FUNCTION until the display indicates "DMX 512 Add." Use the
buttons UP and DOWN, to set the machine to the same address as on your DMX
controller. Please refer to the chapter DMX512 settings for more information on
DMX operation.
-Timer operation
In the time mode, the machine will automatically emit fog. The time intervals, duration,
and fog volume depend on the corresponding menu settings. Press the button TIMER, to
activate the timer mode. The display indicates the set time interval. The unit counts down
to 0 seconds and emits fog. To deactivate the timer mode, press the button TIMER again.
-Continuous operation
Press the button VOLUME, to activate continuous fog output. The display indicates the
value that was set in menu item "Volume Out” i.e. Nonstop Burst, High, Medium or Low. To
stop the fog output, press the button VOLUME once again.
-Manual operation
For immediate fog output at the maximum volume of fog, keep the button MANUAL
pressed. The display indicates "Manual Output". As soon as you release the button, the
fog output will stop. The manual operation will take priority over the continuous operation
and the timer operation. Even if one of these operating modes is activated, the fog
machine will always emit the maximum volume of fog when the button MANUAL is
pressed.
Output volume Output duration Pause between fog ouputs
Nonstop Burst Continuous output* --
High Volume 1 minute 1 minute
Medium Volume 2 Minute 1 minute
Low Volume Continuous output* --
