PARTS LIST
15
Key Qty Description
A 1 TOP LID
B 2 UPPER HINGE
C 1 LOGO PLATE
D 1 HANDLE
E 1 FIREBOX
F 2 LOWER HINGE
G 2 BURNER
H 2 HEAT TENT
I 1 FLAME CARRYOVER TUBE
J 1 ELECTRODE
K 1 GREASE CUP CLIP
L 1 GREASE CUP
M 1 COOKING GRATE
N 1 SWINGAWAY GRID
O 1 LEFT CART FRAME
P 1 RIGHT CART FRAME
Q 1 UPPER LEFT CART FRAME
R 1 UPPER RIGHT CART FRAME
S 1 UPPER CART BRACE
T 1 CONTROL PANEL
U 1 MATCH HOLDER
V 1 IGNITOR
W 1 VALVE HOSE REGULATOR ASSEMBLY
X 1 FRONT PANEL
Y 1 UPPER BACK BRACE
Z 1 LOWER BACK BRACE
AA 1 HEAT SHIELD, TANK
BB 3 CONTROL KNOB
CC 3 BEZEL
DD 2 LEG EXTENDER
EE 2 WHEEL
FF 1 AXLE
GG 2 TANK EXCLUSION WIRE
HH 1 TANK EXCLUSION WIRE, REAR
II 1 SIDEBURNER SHELF
JJ 1 DRIP PAN
KK 1 SIDEBURNER
LL 1 ELECTRODE, F/ SB
MM 1 SIDEBURNER GRATE
NN 1 SIDEBURNER LID
OO 1 RIGHT SHELF ASSEMBLY
NOT Pictured
… 1 HARDWARE PACK
… 1 ASSY INSTRUCTION, ENGLISH
… 1 ASSY INSTRUCTION, SPANISH
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model. However, the method of assembly remains the same.
