Page 10 of 20 COLORrail™ IRC User Manual (Rev. 02)
Wireless Remote Mode
To enable the Wireless Remote Mode, follow the instructions below:
1) Press
2) Press .
Master/Slave Mode
This mode allows a single COLORrail™ IRC unit (the “master”) to control the actions of
one or more COLORrail™ IRC units (the “slaves”) without the need of a DMX controller.
The master unit will be set to operate in either Automatic or Sound Active mode, while the
slave units will be set to operate in Slave Mode. Once set and connected, the slave units
will operate in unison with the master unit.
Configure the units as indicated below.
Slave units:
1) Press repeatedly until SLAU shows on the display.
2) Press to accept.
3) Set the DMX address to “001”, as previously explained.
5) Connect the DMX input of the first slave unit to the DMX output of the master unit.
6) Connect the DMX input of the subsequent slave units to the DMX output of the
previous slave unit.
7) Finish setting and connecting all the slave units.
Master unit:
1) Set the master unit to operate in either Automatic or Sound mode, as previously
indicated.
2) Make the master unit the first unit in the DMX daisy chain.
 Configure all the slave units before connecting the master unit to the DMX daisy
chain.
 Never connect a DMX controller to a DMX string configured for Master/Slave
operation because it may interfere with the signals from the master unit.
 Do not connect more than 31 slave units to the master unit.
