Chauvet CH-444A - Manual

Package contains:
1 x ABYSS II
1 x ELC3 Bulb
1 x Hanging Bracket
2 x Handles
2 x Washers
Troubleshooting
ü If the unit is not functional - check main power supply is on and check fuses.
ü If the unit is functional but lamp does not light - lamp may require replacing.
ü If after trying this solution you still have a problem contact CHAUVET.
Contact Chauvet
USA
Technical Assistance: 1-800-762-1084 (954) 929-1115
E-Mail [email protected]
Caution
Do not obstruct the fan or air vents.
Do not touch unit or lamps while hot.
Do not transport unit while hot.
Never put any objects through the air grill on the top of the unit.
No user serviceable parts inside. Please refer to CHAUVET for service.
Power Connections
The unit is supplied with a power plug appropriate to its voltage and destination. Should any other
connections be required they must be carried out with the following configuration.
Earth = Green/Yellow cable
neutral = Blue cable
Live= Brown cable
In the USA & Europe, it is required that all plugs are 3-pin type i.e. with Earth/Ground connection.
In the UK, it is required that all mains plugs are fitted with 5A fuses.
Technical Specifications
Power 120V~60Hz AC 230V~50Hz AC
Fuse 20mm Glass 3A Fast Blow 20mm Glass 3A Fast Blow
Lamps
1X24V 250W
Part No. ELC3 24V 250W (300 Hrs)
Dimensions 305 x 254 x 127 mm / 12 x 10 x 5 in
Weight 7.5kg / 16.5lbs
ABYSS II
CH-444A
Users Guide
Please read these instructions carefully before use
World-wide Headquarters:
3000 North 29 th Ct.,
Hollywood, Florida, USA 33020
Tel: +1-954-929-1115 Fax: +1-954-929-5560
www.ChauvetLighting.com
User Information (Please complete for your records)
Data Purchased: / / Serial No.:
Dealer Stamp: Model: CH-444A ABYSS II
