Lifting equipment
Tape measure
Level
Pry bar
Marking pen
Wrenches
ASTM A-325 bolts (or equivalent strength), lock
washers, and flat washers to secure Load Disc to
vessel support (if applicable)*
ASTM A-325 (or equivalent strength) anchor
bolts, lock washers, flat washers, and nuts to
secure Load Disc to vessel foundation (if
applicable)*
KM Test Meter or signal processor
Shims (if applicable)
Grout (if applicable)
Digital Multimeter (FLUKE™ or equivalent)
optional
* See TI drawings in Appendix D for the appropriate bolt size.
Prepare Installation
Equipment
(Customer Supplied)
The following equipment is needed to install Load Discs:
Vessel Preparation There are two aspects to successful use of Load Discs — properly
functioning Load Discs and appropriate vessel support
characteristics. Review the following list of error sources, and make
the recommended corrections before you install the Load Discs:
• An inadequate vessel foundation can allow excessive
movement. Ensure the foundation is concrete or steel.
• Hidden load-bearing structures, such as discharge chutes
or plumbing supported by the floor, can reduce loads on
the vessel supports. Install flexible couplings to minmize
this problem.
• Cross-connecting structures, such as catwalks and
manifolds, can transfer loads from adjacent vessels.
Install slip joint or flex couplings to minimize this
problem.
• Shock loads can damage the Load Disc. Install protective
barriers or stops to prevent vehicles from hitting the
vessel supports.
Chapter 2: Preparing for the Load Disc Installation
2-2
